Automated campus vehicle access control infrastructure for Universitas Pembangunan Nasional "Veteran" Jawa Timur, powered by high-frequency RFID chips embedded in Student ID Cards (KTM). Engineered to eliminate rush-hour bottlenecks and empower campus security personnel to prioritize high-level safety and parking facility surveillance.
Directly test student contactless card authentication, academic REST API validation, and real-time electromechanical boom arm kinematics.
Comprehensive diagnostic of vehicular bottleneck queues at UPN "Veteran" Jawa Timur and the technological transition toward an automated security ecosystem.
Manual identity checks at campus entrance checkpoints during peak morning arrival windows cause severe vehicular bottlenecks that spill over onto primary municipal thoroughfares (Jl. Rungkut Madya). Contactless RFID automation slashes verification time to under 1.2 seconds per motorcycle.
By delegating repetitive identity gatekeeping to high-reliability automation, security personnel are liberated from administrative verification, refocusing on active perimeter security, vehicle/helmet loss prevention, and parking lot capacity governance.
The ZKTeco C3-100 industrial controller interfaces via secure REST APIs with the UPNVJT Academic Information System (SIAKAD). Entry is granted exclusively to students with active academic enrollment, ensuring airtight data governance and auditable logs.
End-to-end synchronized stages from contactless RFID interrogation and industrial controller logic to motor actuation and immutable event logging.
Student taps their contactless ID card against the weatherproof ZKTeco KR500M reader on the access stanchion.
The master controller retrieves card UID and queries student status via encrypted REST API calls to SIAKAD.
Relay outputs trigger the high-torque AC motor, smoothly elevating the 4-meter aluminum boom arm in 1.8 seconds.
Subterranean inductive loop detectors and IP66 dual-beam infrared photocells guarantee zero vehicle-impact hazard.
The boom arm safely lowers upon transit completion and permanently commits access timestamps to university servers.
Comprehensive component catalog and investment allocation for the campus automatic gate barrier infrastructure. Official single-gate investment: IDR 27,782,500.
Heavy-Duty Barrier Gate (120W AC Motor), 4m Octagonal Aluminum Boom Arm, 4m Rubber Cushion Buffer Strip, 4.5mm Manganese Balance Spring.
ZKTeco KR500M Contactless Reader (13.56MHz), C3-100 Access Controller, ACR122U USB Desktop Reader, Mifare 1K Cards (50 Pcs Pack).
Dual-Channel Inductive Loop Detector, IP66 Dual-Beam Active Infrared Photocell, IP65 Mini LED Traffic Light, 1 kVA Online UPS, Surge Protection & MCB.
Heavy Conduit & Raceways, SIAKAD REST API Integration Software Module, Concrete Plinth Foundation Works, Professional Installation & 1,000-Cycle Testing.
| No | Component Description | Category | Quantity | Unit Price | Subtotal |
|---|
Strategic deployment blueprint for the 2 automated campus gates from civil groundwork to comprehensive 1,000-cycle stress validation.
Topographical elevation surveying at campus entrances, structural concrete footing layout, and subterranean conduit raceway trenching.
Pouring reinforced concrete plinths, anchoring the 132W AC motor housings, embedding inductive loop sensors, and erecting reader pedestals.
Configuring ZKTeco C3-100 industrial controllers and establishing encrypted REST API bridging with the university student registry.
1,000-cycle automated barrier open-close stress testing, 100-student trial validation, and campus security staff protocol training.
Primary arterial gateway for student motorcycles, cars, faculty, and campus visitors originating from Jl. Rungkut Madya Surabaya.
Circulation checkpoint adjacent to Science and Laboratory faculties, purposefully configured to divert peak morning vehicular density.
The stylized "P" monogram fuses the international parking designation with the ascending silhouette of an automated barrier arm. The institutional blue gradient conveys digital precision, electromechanical reliability, and ordered campus mobility.
Interdisciplinary collaboration among undergraduate engineering students at Universitas Pembangunan Nasional "Veteran" Jawa Timur.
